Product Details:
|
| Material: | MC3/MC3+L | Type: | Machining Services |
|---|---|---|---|
| Size: | OEM Accepted | Application: | For Steel Pipes Surface Cutting |
| Product Name: | Tungsten Inserts | Sample: | Available |
| Highlight: | High precision thread cutting carbide inserts,MC3 thread cutting carbide inserts,MC3+L thread carbide inserts |
||
Thread Turning Insert Thread Cut Tool Threading Inserts Carbide
Description
A carbide threading insert is a tool used in the machining process to create internal threads in parts. It consists of a solid piece of carbide that has been precision-machined to form a cutting edge. The insert is designed to cut threads in a variety of materials, including steel, stainless steel, brass, aluminum, and plastic. The insert is typically inserted into a tool holder or machine chuck and then used to cut threads in the part. The cutting edge on the insert is designed to cut threads with a precise shape and size. The insert also has a wear resistant coating to help it last longer and maintain its cutting edge. Carbide threading inserts provide an efficient, accurate, and fast way to create threads in parts.
Product Features
High-quality threading: High-quality threading refers to the creation of threads to exact specifications and tolerances, using quality materials and construction methods to ensure a reliable and durable product.
Cost-effective: Cost-effective threading refers to the use of efficient methods and materials to create threads while minimizing material costs and labor costs.
Long tool life: Long tool life refers to the ability of a threaded tool to maintain its shape and function over an extended period of time, with minimal maintenance and upkeep.
Easy to use: Easy-to-use threading refers to the ability of a threading tool to be easily operated and used with minimal instruction or experience.
High-precision threading: High-precision threading refers to the creation of threads to exact dimensions and tolerances, using specialized tools and techniques to ensure accuracy and repeatability.
Materials
The selection of thread cutting insert materials varies depending on the workpiece material to achieve better cutting performance.
Some optional Carbide Grade:
| Metal Grade | performance and use |
|
MC1 |
MC1 exhibits exceptional matrix red hardness and remarkable toughness, making it ideally suited for processing with high-efficiency threading machines. Furthermore, it is perfectly compatible with the threading requirements of oil pipes, casings, and couplings that belong to medium steel grades and secondary high steel grades, encompassing materials like J55, K55, N80, L80. |
| MC2 |
MC2 boasts high matrix strength, excellent red hardness, and good impact resistance. It is suitable for high-efficiency threading machine processing of medium to high steel grade oil pipes, casings, and coupling threads, such as N80 and P110. |
| MC3 |
MC3 boasts good overall mechanical properties in its matrix, along with stable cutting performance. It is suitable for high-efficiency threading machine processing of oil pipes, casings, and coupling threads that belong to low, medium, and secondary high steel grades, such as H40, J55, M65, C75, N80, and similar specifications. |
| P35 |
P35 utilizes a matrix with high strength and excellent red hardness, making it suitable for processing the threads of drill pipes, oil drilling collars, sucker rods, and other related equipment. |
| YT15 |
Depending on the specific application, it can be coated or uncoated, and possesses good red hardness and toughness. It is suitable for use in the manufacturing of specialized chip breakers for thread cutting combs and other cutting tools. |
| S Material |
Exhibits excellent wear resistance and high-temperature red hardness, making it suitable for the internal threading of medium to high alloy steels. |
| Name | Description | Features | Application Areas |
| ISO | ISO Metric Full Profile Thread Insert is a tool with a complete thread profile, designed to meet ISO Metric thread standards. |
Complying with ISO standards ensures that the processed threads have uniform size and precision, and the full-profile design improves processing efficiency. Made of high-quality materials, with high hardness and wear resistance
|
|
| W | Threads specially designed for pipe connections | The tooth angle of Whitworth thread is 55°, which is different from many other thread standards. The rounded top and bottom of the thread can reduce the wear of the thread tool on the top and improve its fatigue resistance. |
|
| TR | 30° Trapezoidal thread | Trapezoidal thread refers to a metric trapezoidal thread with a tooth angle of 30°.Trapezoidal threads are mainly used for transmission, have high strength and rigidity requirements, are not easy to loosen, and have high transmission efficiency. |
|
| ACME | ACME trapezoidal thread cutter is a tool specially designed for processing ACME trapezoidal threads, with specific angle and shape design. |
The ACME thread usually has a tooth angle of 29° (there are other angles such as 30°, but 29° is the most common), and the tooth profile is trapezoidal, wider at the bottom and narrower at the top.
|
|
| UNJ | UNJ thread is a mechanical thread with high strength and durability, especially suitable for applications requiring high strength and reliable connection. |
High strength: Compared with cUNJ threads have higher strength. The external thread bottom of UNJ threads is in an arc shape. This design helps to reduce stress concentration and increase the fatigue life of the threads.
|
|
| NPT | The NPT thread has a tooth angle of 60° and a taper of 1:16. |
NPT threads can provide reliable sealing performance. NPT threads comply with the US National Pipe Thread Standard (ANSI/ASME B1.20.1, etc.) and have good versatility and interchangeability.
|
|
| NPTF | NPTF thread is a thread standard for pipe connections developed by the American National Standards Institute (ANSI), mainly used in North America. |
Sharp tooth shape and short root: higher connection stability and security. NPTF thread has good self-locking performance, can provide greater load-bearing capacity, high tooth shape accuracy, and can prevent leakage without sealing medium.
|
|
For more than three decades, Minjiang has built a name for itself as a dependable, reliable associate in the business. Our enthusiasm for quality and invention is unrivaled in the sector, with a team of professionals devoted to offering customized guidance and solutions specific to every single customer's requirements. We are devoted to crafting an exclusive and beneficial experience for our customers, employing the most advanced technologies and eco-friendly materials for optimum effect. Moreover, we guarantee amazing customer service, guaranteeing a smooth and stress-free journey for every customer. With Minjiang, you can always anticipate a top-notch, dependable product and service each time.
A: Yes, we often make customized products.
2. Q: Do you provide free samples?
A: We can provide free samples, but do not undertake the freight cost.
3. Q: What is the benefit of using Carbide Threading Inserts?
A: Carbide Threading Inserts offer several benefits over traditional threading methods. They are highly precise, provide a superior surface finish, and are capable of producing high thread accuracy with minimal tool wear. Carbide Threading Inserts also require less torque and power to produce threads, reducing cutting time and costs.
